March 2017
Page A-3
“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Chassis Assembly -- 1930SE
ITEM PART NO. QTY DESCRIPTION
1 41771 1 Battery Module
2 41772 1 Chassis Weldment
3 41310 1 Beacon
4 41309 1 Cover
5 53038 6 Washer, M5
6 53042 2 Screw, M5 x 16
7 53043 6 Washer, M5 Spring
8 41370 1 Trim Lock
9 41773 1 Limit Switch Assembly
10 41435 1 Pipe Bracket Assembly
11 41774 1 Steering Wheel Assembly
12 53056 2 Screw, M5 x 12
13 41775 1 Lower Controls Panel
14 41776 1 Controls Module
15 41777 1 Controls Cover
16 53044 2 Screw, M5 x 10
17 41778 1 Pothole Protection Assembly, 1930S E
18 41778 2 Spacer
19 50343 4 Screw, FHSC M8 x 20
20 41003 1 Static Strap
21 50000 9 Washer, M6
22 53046 1 Washer, M6 Spring
23 53051 1 Bolt, M6 x 16
24 41069 1 Battery Charger
25 53058 4 Screw, M6 x 12-H
26 50047 4 Nut, M6
27 41780 1 Bracket
28 50001 2 Washer, M8
29 50030 2 Bolt, M8 x 20
30 41575 2 Plug Socket
31 53034 4 Screw, M4 x 12
32 50033 4 Bolt, M10 x 25
33 53054 4 Washer, M10 Spring
34 41781 1
Ladder - 3 Step, ~ Serial # 164000294
36
41782 2 Rear Wheel Assembly, 1930SE
35
1
Ladder - 2 Step, Serial # 164000295 ~
41745
