March 2017
Page A-5
“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Chassis Assembly -- 2632SE
ITEM PART NO. QTY DESCRIPTION
1 41783 1 Battery Module Assembly
2 41784 1 Chassis Weldment
3 41310 1 Beacon
4 41309 1 Cover
5 53038 4 Washer 5
6 53043 4 Spring washer 5
7 53042 2 Screw M5×16-H
8 41370 1 Trim Lock
9 41371 1 Limit Switch Assembly
10 41450 1 Pipe Bracket Assembly
11 41438 1 Steering Wheel Assembly
12 41439 1 Ground Controls Assembly
13 53045 2 Screw M5×14-H
14 41440 1 Control Module Assembly
15 41375 2 Spacer
16 50348 4 Screw M8×25
17 41437 1 Pothole Protection Assembly
18 41003 1 Static Strap
19 53046 1 Spring washer 6
20 50028 1 Bolt M6×20
21 53070 4 Bolt M14×35
22 53048 4 Spring washer 14
23 53049 4 Washer 14
24 41374 1 Ladder
25 41441 2 Rear Wheel Assembly
26 41575 1 Plug Socket
27 53034 2 Screw, M4 x 12
