March 2017
Page A-7
“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Chassis Assembly -- 3346SE, 4046SE
ITEM PART NO. QTY DESCRIPTION
1
41785 1 3346SE -- Battery Module Assembly
41786 1 4046SE -- Battery Module Assembly
2 41787 1 Chassis Weldment
3 41310 1 Beacon
4 41309 1 Cover
5 53038 4 Washer 5
6 53043 4 Spring washer 5
7 53042 2 Screw M5×16-H
8 41370 1 Trim Lock
9 41371 1 Limit Switch Assembly
10 41435 1 Pipe Bracket Assembly
11 41453 1 Steering Wheel Assembly
12 41439 1 Ground Controls Assembly
13 53045 2 Screw M5×14-H
14 41455 1 Control Module Assembly
15 41457 1
4046SE Only -- Counterweight
16 50051 2
4046SE Only -- Nut, M16
17 50004 4
4046SE Only -- Washer, M16
18 53050 2
4046SE Only -- Bolt, M16 x 220
19 41459 Pothole Protection Assembly
20 41375 2 Spacer
21 50348 4 Screw M8×25
22 53051 2 Bolt, M6 x 16
23 50000 3 Washer, M6
24 41461 2 Rubber Pad
25 41372 1 Static Strap
26 53046 1 Washer, M6 Spring
27 50028 1 Bolt M6×20
28 41575 1 Plug Socket
29 53034 4 Screw, M4 x 12
30 53070 4 Bolt M14×35
31 53048 4 Spring washer 14
32 53049 4 Washer 14
33
41464 1 3346SE -- Ladder
41465 1 4046SE -- Ladder
34 41441 2 Rear Wheel Assembly
To Next Page
