March 2017
Page A-9
“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Chassis Assembly -- 4555SE
ITEM PART NO. QTY DESCRIPTION
1 41788 1 Battery Module Assembly
2 41789 1 Chassis Weldment
3 41310 1 Beacon
4 41309 1 Cover
5 53038 4 Washer 5
6 53043 4 Spring washer 5
7 53042 2 Screw M5×16-H
8 41370 1 Trim Lock
9 41371 1 Limit Switch Assembly
10 41435 1 Pipe Bracket Assembly
11 41454 1 Steering Wheel Assembly
12 41439 1 Ground Controls Assembly
13 53045 2 Screw M5×14-H
14 41790 1 Control Module Assembly
15 41791 1 Pothole Protection Assembly
16 50034 2 Screw M10×30
17 41462 2 Rubber pad
18 41375 2 Spacer
19 50348 4 Screw M8×25
20 41372 1 Static Strap
21 53046 1 Spring washer 6
22 50000 4 Washer 6
23 50028 1 Bolt M6×20
24 41575 1 Power Plug
25 53034 4 Screw, M4 x 12
26 41465 1 Ladder
27 53070 4 Bolt M14×35
28 53048 4 Spring washer 14
29 53049 4 Washer 14
30 41441 2 Rear Wheel Assembly
To Next Page
