“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Steering Wheel Assembly -- 1930SE
ITEM PART NO. QTY DESCRIPTION
-- 41774 1 Steering Wheel Assembly, 1930SE
1 41593 1 Steering cylinder
-- 41594 1 Seal kit
2 41225 4 Bearing
3 41321 2 Pin
4 41322 2 Cotter Pin
5 41226 2 Thrust Washer
6 41210 4 Bearing
7 41596 2 Cover
8 41595 4 Bearing
9 41603 2 Strain Relief
10 41792 2 Seal
11 41793 1 Steering Yoke, Left
12 41794 2 Screw
13 41795 2 Drive Motor Assembly
-- 41796 2 Gear Reduction
-- 41797 2 Motor
-- 41601 2 Brake
14 50032 24 Bolt, M8 x 30
15 53055 24 Washer, M8 Spring
16 50001 24 Washer, M8
17 41591 2 Wheel
18 -- -- --
19 41597 2 Cover
20 53038 8 Washer, M5
21 53043 8 Washer, M5 Spring
22 53056 8 Screw, M5 x 12
-- -- --
--
24 41222 2 Bearing
25 41799 1 Tie Rod
26 50002 2 Washer, M10
27 50049 2 Nut, M10
28 41925 Steering Yoke, Right
29
41926
Motor Baffle
30 53095
Screw M10 x 20
1
2
8
