“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Rear Wheel Assembly -- 1930SE
ITEM PART NO. QTY DESCRIPTION
-- 41782 2 Rear Wheel Assembly, 1930 SE
1 50032 6 Bolt, M8 x 30
2 53055 12 Washer, M8 Spring
3 50001 12 Washer, M8
4 41591 1 Wheel
5 50457 6 Screw M8×20
6 41237 1 Cap
7 41024 2 Bearing
8 41803 1 Plate
9 50032 6 Bolt, M8 x 30
10 41804 1 Spindle
11 41805 1 Terminal Pad
12 50236 4 Bolt, M12 x 40
13 53053 4 Washer, M12 Spring
14 50003 4 Washer, M12
15 41322 1 Cotter Pin, 4 x 40
16 41023 1 Seal
17 41237 1 Washer
18 41236 1 Nut, M16-1.5 Castle
To Next Page
