March 2017
Page A-19
“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Pothole Protection Assembly -- 1930SE
ITEM PART NO. QTY DESCRIPTION
-- 41778 1 Pothole Protection Assembly
1 41806 1 Pothole Guard
2 50010 4 Bolt, SHCS M8 x 25
3 53055 4 Washer, M8 Spring
4 41036 2 Switch
5 50001 4 Washer, M8
6 50050 4 Nut, M12
7 41807 1 Hasp
8 41604 4 Axle Bolt
9 41051 4 Bearing
10 41210 4 Bearing
11 53049 6 Washer, M14
12 50303 6 Nut, M14
13 50005 2 Washer, M20
14 50002 4 Washer, M10
15 50052 2 Nut, M20
16 50049 4 Nut, M10
17 41808 1 Hasp
18 41041 1 Linkage Weldment
19 41809 1 Pothole Guard
20 41395 1 Actuator Seat
21 41605 2 Pothole Actuator Weldment
22 41606 2 Pothole Actuator Pin
23 41055 2 Bearing
24 41053 2 Spring
25 50035 4 Bolt, M10 x 40
26 41040 2 Thrust Washer
27 53056 2 Screw, M5 x 12
28 41049 2 Roller
29 41030 1 Linkage Weldment
30 41046 4 Bearing
31 41047 2 Axle Bolt
32 41048 2 Axle Pin
33 41810 2 Rear Linkage
34 41043 4 Bearing
35 41045 2 Gas Spring
36 41044 2 Gas Spring Axle
37 53081 4 Screw, M5 x 12
38 53082 4 Screw, M5 x 35
39 53043 8 Washer, M5 Spring
40 53038 8 Washer, M5
41 41035 2 Switch Cover
