March 2017
Page A-23
“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Battery Module Assembly -- 1930SE
ITEM PART NO. QTY DESCRIPTION
-- 41771 1 Battery Module Assembly, 1930SE
1 41811 4
Battery, Trojan T605
2 41812 1 Brace
3 50001 2 Washer, M8
4 50048 2 Nut, M8
5 41813 2 Pin
6 41037 4 Bearing
7 41814 2 Spacer Washer
8 50005 2 Washer, M20
9 41355 2 Snap Ring
10 41815 1 Battery Tray
11 53044 1 Screw, M5 x 10
12 53038 1 Washer, M5
13 41461 1 Bumper
14 41067 1 Latch
15 50047 2 Nut, M6
16 50000 2 Washer, M6
17 53046 2 Washer, M6 Spring
18 50214 2 Bolt, M6 x 30
19 41607 1 Power Switch
20 53051 2 Screw, M6 x 16-H
21 41068 1 Handle Ring
