March 2017
Page A-27
“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Control Module Assembly -- 1930SE
ITEM PART NO. QTY DESCRIPTION
1 41037 4 Bearing
2 41813 2 Pin
3 41077 1 Oil Filter
-- 41078 1 Filter Element
4 53046 4 Washer, M6 Spring
5 50025 2 Bolt, M6 x 20
6 41817 1 Filter Bracket
7 50047 3 Nut, M6
8 50000 5 Washer, M6
9 53014 8 Nut, M8
10 50001 8 Washer, M8
11 41818 1 Hydraulic Tank Assembly
12 41070 1 Hour Meter
13 41819 1 Controls Module Weldment
14 41068 1 Handle Ring
15 50117 2 Bolt M6×25
16
42
896 1 Latch
17 41074 1 Alarm
18 50031 6 Screw M8×25
19 41075 1 Horn
20 50276 2 Screw, FHSC M8 x 25
21 50457 4 Screw, FHSC M8 x 20
22 41608 1 Pump Assembly
-- 41820 -- Motor
-- 41609 -- Pump
23 53051 2 Screw M6×16-H
24 41461 1 Bumper
25 53038 8 Washer, M5
26 53044 1 Screw, M5 x 10
27 41821 1 Motor Controller Assembly
28 50524 7 Nut, M5
29 41080 1 ECU Module
30 41081 1 Functions Manifold
31 53055 4 Washer, M8 Spring
32 41355 2 Snap Ring
33 50005 2 Washer, M20
34 41814 2 Spacer Washer
To Next Page
