March 2017
Page A-31
“SE Series” Parts Section
• as req: as required • INCL: Included with assembly • NS: Not a Stock item • REF: Reference only
Hydraulic Tank Assembly -- 1930SE
ITEM PART NO. QTY DESCRIPTION
-- 41818 1 Hydraulic Tank Assembly
1 41412 2 Washer 22
2 41085 1 Fitting M22×1.5
3 41413 1 Nut
4 41167 1 Seat
5 41166 1 Bolt
6 53049 1 Washer, M14
7 41082 1 Breather Nut
8 41823 1 Hydraulic Tank
9 41412 1 Washer 18
10 41087 1 Drain Plug
11 41824 1 Filter
12 41825 1 Suction Pipe
13 41826 1 Fitting
To Next Page
