PULSE - The relay will be activated momentarily
when the load limit is reached.
Select the desired function and press the ENTER key.
The display will show SET and a default load limit at which
the output signal will trigger the relay.
To set the required load limit use UP and DOWN keys to
adjust the value and ENTER to confirm the selection.
Negative load limits indicate compression.
The display will revert back to PLC sub-menu 1 and PLC ON
will now be displayed.
Press ESC to return to main-menu page 1.
The AFG may be used to send a signal to control the
Mecmesin range of motorised test stands via a dedicated
cable.
To configure the signal output from the AFG, press and hold
the MENU key until page 1 of the main-menu appears. Press
DOWN to move the arrow cursor to STAND and press the
ENTER key.
The display will show:-
STAND OFF - Indicates status of stand control function.
REVERSE - Reverses the stand direction of travel at
sample break (BREAK) or load-limit value
(LIMIT). The test stand will reverse back to
the start position as defined by the
physical Microswitch.
STOP - Stops the stand at sample break (BREAK)
or load-limit value (LIMIT). The test stand
does not return to the start position.
CYCLE - Cycles a suitable test stand between load
limits (UPPER, LOWER) for a set number of
times (CYCLE).
Select the desired function using UP and DOWN keys and
press ENTER to select.
PLC sub-menu 2
STAND
Contact your supplier for stand
interface cable
STAND sub-menu 1
