page 24
The transmission (or Baud) rate can now be set.
Use the UP or DOWN key to position the arrow cursor at the
relevant speed (2400, 9600, 57600 or 115200). Press
ENTER to select.
You will now return to page 2 of the main-menu.
To set STORE MEM press ENTER from Comms sub-menu 1.
This will cause a memory counter to appear in the main
display. You will now return to page 2 of the main-menu.
To set SEND MEM press ENTER from Comms sub-menu 1.
This will cause a TX symbol to flash in the main display as the
memory data is now transmitted to a peripheral device. The
data is transmitted at the settings defined by PORT. After
transmission of data you will now return to page 2 of the
main-menu.
To set CLEAR MEM press ENTER from Comms sub-menu 1.
This now erases all the data stored in the memory. The
memory counter is now reset to zero. After clearing the
memory you will now return to page 2 of the main-menu.
A constant of multiplication can be applied to the load values
in the main display. This is useful for applications where you
wish to convert the load reading into a non-standard unit of
measurement e.g. for co-efficient of friction tests.
Press ENTER to select xCONSTANT. Press UP or DOWN to
adjust the constant of multiplication. Press ENTER to confirm.
Displays calibration information.
T - Tension span
C - Compression span
Z - Current zero
G - Gravitational constant
I - True zero at time of calibration
This is for information only and may be required for
diagnostic purposes by your distributor.
Calibration menu - displays a password menu and allows the
user to check for load cell offset if overload is suspected.
Port sub-menu 2
x/CONSTANT
INFORMATION
CALIBRATION
