page 26
AFG SPECIFICATIONS
RANGE & RESOLUTION
Model no: mN N kN gf kgf ozf lbf
AFG2.5 2,500 x 0.5 2.5 x 0.0005 - 250 x 0.05 - 9 x 0.002 0.55 x 0.0001
AFG 5 5,000 x 1 5 x 0.001 - 500 x 0.1 0.5 x 0.0001 18 x 0.005 1.1 x 0.0002
AFG 10 10,000 x 2 10 x 0.002 - 1,000 x 0.2 1 x 0.0002 35 x 0.01 2.2 x 0.0005
AFG 25 25,000 x 5 25 x 0.005 - 2,500 x 0.5 2.5 x 0.0005 90 x 0.02 5.5 x 0.001
AFG 50 50,000 x 10 50 x 0.01 - 5,000 x 1 5 x 0.001 180 x 0.05 11 x 0.002
AFG 100 - 100 x 0.02 - 10,000 x 2 10 x 0.002 350 x 0.1 22 x 0.005
AFG 250 - 250 x 0.05 - 25,000 x 5 25 x 0.005 900 x 0.2 55 x 0.01
AFG 500 - 500 x 0.1 - 50,000 x 10 50 x 0.01 1,800 x 5 110 x 0.02
AFG 1000 - 1,000 x 0.2 1 x 0.0002 - 100 x 0.02 3,500 x 1 220 x 0.05
ACCURACY
± 0.1% of full-scale
Calibration temperature: 20°C ± 2°C
Operating temperature: 10°C - 35°C
Temperature shift at zero load: ± 0.01% of full-scale/°C
OUTPUT
RS232-C: 8 data bits, 1 Start bit, 1 Stop bit, no parity
Digimatic (Mitutoyo) format BCD output
Analogue: 0 to +4V full scale for tension (or clockwise)
0 to -4V full scale for compression ( or counter-clockwise)
(calibrated to order at factory)
PLC Signals: Relay description
The solid-state relay is mounted on a
PCB,which is hosed in a 15 pin D-type connector.
Connection to the relay output is via a 5metre length
screened cable. The end of the cable is left with bare
wires to allow appropriate termination to the peripheral
PLC device.
