page 23
To assign the function of a key to FOOTSWITCH 2 use UP
and DOWN to move the arrow key to FOOTSWITCH 2.
Using UP and DOWN select the relevant key (MAX, UNITS,
TXD, ZERO or RESET) and press the ENTER key.
Press ESC to return to page 2 of the main-menu.
Communications settings are selected to configure interfacing
of the AFG with peripheral devices. Also used to configure
the AFG to store up to a maximum of 100 readings in the
internal memory.
To set communications first use UP and DOWN keys to move
the cursor arrow to COMMS on page 2 of the main-menu.
Using UP and DOWN select the relevant option (see below)
and press the ENTER key.
PORT - Communicates with peripheral device.
Transmission of the displayed load reading
can be set to include unit of measurement
(UNITS ON or OFF) and BAUD rate can
also be set.
STORE MEM - Stores a single load reading to the internal
memory. With this option selected, pressing
the TXD key when in the MAX modes of the
main display will send the displayed value to
memory. Up to 100 readings may be stored
in the memory. As each reading is stored, a
‘REC’ symbol appears on the main display
to indicate a reading has been stored in the
memory.
SEND MEM - Sends all load readings stored in the internal
memory to a peripheral device (e.g PC or
data logger).
CLEAR MEM – Erases all load readings stored in memory.
When setting PORT you will now access sub-menu 1.
Transmission of the displayed load reading can be set to
include the unit of measurement (UNITS ON or OFF).
Use the UP or DOWN key to position the arrow cursor at
either UNITS OFF or ON. Press ENTER to select.
FOOTSWITCH 2
COMMS
COMMS sub-menu 1
Port sub-menu 1
