Fitting of alkaline batteries
USING THE GAUGE
Fitting accessories
Note: When fitting a grip ensure
that it is screwed finger-tight only.
Excessive torque can damage
the load cell.
Mounting to a test stand
If rechargeable batteries are fitted, a trickle charge will be
applied to the batteries.
The AFG can also be powered by AAA 1.5V alkaline
batteries (not supplied). For the fitting of alkaline batteries,
follow fitting instructions as per rechargeable batteries above.
Warning: When alkaline batteries are fitted, the mains
adaptor/charger must NEVER be connected to the AFG due
to the risk of acid leakage which could damage the
instrument.
The Rotary Coupling is supplied with AFG instruments
between capacities of 10N to 1000N. It allows operators to
orientate the gripping accessory without the need for a
locking wheel (as on the extension rod).
We do not recommend it to be used for AFG 2.5N and 5N
due to its weight, which would need to be tared from the
measuring range.
Affix the Rotary Coupling to the male thread of either the short
extension rod (30mm long) or the long extension rod (130mm
long). Affix the extension rod to the load cell probe in the
hole at the bottom of the gauge by tightening it gently with
the fingers.
Your chosen grip or accessory may now be connected to the
rotary coupling.
On the rear of the gauge there are two M5 threaded holes,
which can be used for mounting the gauge to a Mecmesin
test stand.
Each Mecmesin test stand is supplied with a dedicated
‘dovetailed mounting bracket’ and screws for this purpose.
If you wish to mount to another type of stand, ensure that the
screws used are threaded into the gauge to a maximum
depth of 5.5mm. The final thread is peaned but if screws are
fitted beyond this depth, damage to the internal PCB may
occur.
page 3
