Medeli DP280K - Instrument Setup and Assembly; Piano Assembly Instructions

Setup
This section contains information about setting up your instrument and preparing to play. Please go through this section
carefully before turning the power on.
Setup Guide
To assemble the stand, you will need a Phillip's screwdriver (not supplied). Check that all the parts listed below are included
before proceeding.
06
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Piano body
Left leg
Right leg
Pedal box
Big back board
Screw 6 X 50 (4 pcs)
Hand screw (2 pcs)
Screw M6 X 18 (4 pcs)
Screw 4 X 15 (4 pcs)
Screw cap (4 pcs)
Pedal cable
AC power adaptor
1
5
6
7
8
9
10
11
2
4
3
12
