5.9.3 Secondary Vector Select
Secondary vector groups and phasing
displayed are determined by the standard
and primary vector selected.
Secondary vectors are separated by group and by
phasing. Only typical vector phases are displayed as
selectable options.
5.9.4 Secondary Vector Select
Buttons
Button Description
See Primary Vector
Selection Screen (5.9.2)
Phase Shift
See Phase Shift Selection
(5.9.5)
Optional SW Feature
Primary Vector
Test Voltage
Output
Find Vector
See Find Vector
(5.9.6)
Information subject to change without notice 25
5.9.2 Primary Vector Select
The available primary vectors are displayed below.
Select a primary vector to proceed to the Secondary
Vector selection screen.
Operation
