5) Set P03.24 as 1 or 2, press the ENTER/DATA key and the RUN key, and then the auto-tuning will be
started.
6) When the running LED on the operation panel is off, it indicates that the auto-tuning is finished.
 Note
1. When P03.24 is set as 2, if over-voltage or over-current occurs during the auto-tuning, properly increase
the acceleration/deceleration time (P02.13 and P02.14; for motor 2, please change P11.04 and P11.05 for
tuning).
2. When P03.24 is set as 2 for rotation setting, disconnect the motor shaft from the loads. It is prohibited to
carry out rotation setting when the motor is connected to loads.
3. Before the auto-tuning, the motor shall be in static status, otherwise, the auto-tuning cannot be normally
conducted.
4. In certain situations (for instance, the motor cannot be disconnected from the loads) where it is
inconvenient to conduct rotation setting, or the users does not have high motor control performance
requirement, static setting can be selected, or the setting can be exempted. If the setting is not performed, be
sure to enter the correct nameplate parameters of the motor.
5. If you know the correct motor parameters, please enter the correct motor parameters P03.00~P03.10 (or
P03.12~P03.22).
6. If the auto-tuning fails, Er.TUN error will be reported.
6.5 VF control parameters (Group P07)
P07.00~P07.06 are used to determine different V/F curves of motor 1 under different V/F control modes.
Reserved 0
P03.25～P03.28
Motor 1V/F voltage 1
0~P07.04
(
0.0%
)
P07.06
Motor 1V/F frequency 1
0.00~P07.03
(
0.00Hz
)
P07.05
Motor 1V/F voltage 2
P07.06~P07.02
(
0.00Hz
)
P07.04
Motor 1V/F frequency 2
P07.05~P07.01
(
0.00Hz
)
P07.03
Motor 1V/F voltage 3
P07.04~100.0%
(
0.0%
)
P07.02
Motor 1V/F frequency 3
P07.03~P03.03
(
0.00Hz
)
P07.01
Motor 1 V/F curve setting
0, 17
~
19
(
0
)
P07.00
