1) Jog running: When the drive receives the jog running command in stopping state, it will run according
to the jog frequency (refer to function codes P11.16~P11.18).
2) Process closed loop running: When the process closed loop selection function is enabled (P02.04=6),
the drive will adopt the process closed loop running mode, that is, it will conduct closed loop adjustment
according to the reference and feedback (refer to function code of Group P14). The process closed
loop running mode can be disabled via the multi-functional terminal (function no. 29). If there is a
running command at that moment, it will run at 0 Hz.
3) PLC running: When the PLC function selection is enabled (P02.04=5), the drive will select the PLC
running mode and run according to the preset running mode (refer to the description of the function
codes of P13.16~P13.46).
。
4) Multi-speed running: The multi-speed function selection can be enabled (P02.04=7) via the ON/OFF
combinations of the multi-functional terminals (functions 6, 7, 8 and 9), multi-stage frequency 1~15
(P11.01~P11.15) can be selected for multi-speed running.
Note: Only when 0 is selected for P11.00 the
multi-functional terminal input can be enabled, the multi-stage frequency setting is the maximum
frequency percentage, if it is negative, then the frequency will run reversely. If all the three terminals
are in OFF status or fail to meet the above conditions, the multi-speed will run at the main reference
frequency digital set value (P02.05).
Note
For the specific frequency reference channels of each running mode under the speed control mode, please
refer to
Chapter 6 Parameter Description.
4.3 Initial power-up
4.3.1 Inspection before power-up
Conduct wiring connection according to the technical requirements specified in chapter 3 wring of drive.
4.3.2 Initial power-up operation
When the drive passes the wiring and power supply inspection, turn on the circuit breaker of the AC power
supply at the drive input side to apply power to the drive. The operation panel of the drive will first display
“8.8.8.8.8”, and then the contactor will normally engage. When the characters displayed in the digital tube
change into the set frequency, it indicates that the drive initialization is finished.
If the LED above the M key on the operation panel is ON, it indicates that it is in the operation panel control
status.
The initial power-up process is as shown in Fig.4-10.
