9
function, two sets of motor parameters switching
Basic frequency 0.01Hz~3000.0Hz
Startup frequency 0.00Hz~60.00Hz
Frequency setting mode
Digital panel setting, terminal UP/DN setting, host device communication setting,
analog setting (AI1/AI2), terminal pulse setting, fieldbus communication setting
Acceleration/deceleration
time
0.1~3600.0 (unit can be selected among 0.1s, s and min)
Dynamic braking
capacity
G:18.5kW and below have built-in braking unit as standard, 22kW~75kW can
customize built-in braking unit,braking rate: 0.0~100.0%
P:18.5kW and below have built-in braking unit as standard, 22kW~90kW can
customize built-in braking unit,braking rate: 0.0~100.0%
DC braking capacity
Initial frequency: 0.00Hz~60.00Hz
Braking time: 0.1s~30.0s
Braking current: 0%~100% for model G, 0%~50% for model P; according to the
nominal rated current of the drive
Terminal functions Please refer to the introduction of terminal functions for details
Protection
function
Refer to “Protection function” section for details.
Others
Efficiency ≥93% (7.5kW and below); ≥95% (45kW and below); ≥98% (55kW and above)
Installation method Wall-mounted
Protection degree IP20
Cooling mode Air cooling with fan control
Environment
Operating site
Indoor, away from direct sunlight, free from corrosive gas, combustible gas, oil
mist, water vapor, water dripping or salt
Altitude
Used at the place lower than 1000m, (derated at the place above 1000m, derated
1% for every increase of 100m)
Ambient temperature
-10℃~+40℃ (derated when used in the ambient temperature of 40℃~50℃)
Humidity 5%~95%RH, non-condensing
Vibration Less than 5.9m/s
2
(0.6g)
Storage temperature
-40℃~+70℃
1.5 Drive structure
