230
Appendix 2 Braking Components
1. Built-in brake unit drive selection
1) Brake resistor configuration
Attached Table 2-1 Brake resistor accessory
Motor rated power (kW) Braking resistor model Braking torque (%)
0.4
70W/750
200
0.75 70W/750 120
1.5 260W/400 120
2.2 260W/250 140
3.7 390W/150 180
5.5 500W/100 120
7.5 500W/75 200
11 800W/50 200
15 1000W/40 200
18.5 1300W/30 200
22 1500W/25 200
30 2500W/20 150
37 3700W/15 120
45 4500W/15 200
50 5000W/15 200
55 5500W/10 160
75 9600W/13.6*2 120
90 9600W/13.6*2 200
Note
The drives of 75kWG / 90kWP and below have built-in braking unit or can customize built-in braking unit. The
user only needs to configure external braking resistor when the dynamic braking is required. The drives of
90kWG / 110kWP and above need external braking unit, the wiring between the external braking unit and the
drive, braking resistor selection, etc.,please follow the guidance of external braking unit suppliers.
2) Wiring diagram of the drive which has built-in braking unit and the braking resistor
