8
MV200P-4T55 72.0 113.0 110.0 55
R7
MV200P-4T75 100.0 157.0 152.0 75
MV200P-4T90 116.0 180.0 176.0 90
R8
MV200P-4T110 138.0 214.0 210.0 110
MV200P-4T132 167.0 256.0 253.0 132
R9
MV200P-4T160 200.0 307.0 304.0 160
MV200P-4T200 250.0 385.0 380.0 200
MV200P-4T220 280.0 430.0 426.0 220
R10
MV200P-4T280 355.0 525.0 495.0 280
MV200P-4T315 445.0 590.0 585.0 315
R11
MV200P-4T355 500.0 665.0 650.0 355
MV200P-4T400 565.0 785.0 725.0 400
1.4 Technical specifications of product
Table 1-3 Technical specifications of drive
Input power
Rated voltage (V)
Three-phase: 380V~480V; continuous fluctuation of voltage: ±10%, transient
fluctuation of voltage: -15%~+10%; Voltage unbalance rate: 3%, the distortion
rate complies with IEC61800-2
Rated input current (A) Please refer to Table 1-1 and Table 1-2
Rated frequency (Hz) 50Hz/60Hz, fluctuation range: ±5%
Output
power
Standard applicative
motor (kW)
Please refer to Table 1-1 and Table 1-2
Rated capacity (kVA)
Rated current (A)
Output voltage (V)
Output with three-phase under rated input conditions: 0 ~ rated input voltage, the
error is less than ±3%
Output frequency (Hz) 0.00~3000.0Hz,the minimum unit: 0.01Hz
Overload capacity
G: 1 min for 150% rated current, 0.5 s for 200% rated current
P: 1 min for 110% rated current, 1 s for 150% rated current
Operation
control
features
Control mode High-performance vector control
Maximum output
frequency
3000Hz
Speed adjusting range 1: 100
Speed control precision ±0.5%
Speed fluctuation ±0.3%
Startup torque 150% @ 0.5Hz
Product
functions
Key functions
Fast tracking, multi-stage speed operation, multiple acceleration/deceleration
time switching, auto-tuning, S curve acceleration/deceleration, slip compensation,
fan control, skip frequency operation, energy saving operation, PID adjustment
(sleep function), non-stop upon instantaneous power interruption, switching of
multi-command, MODBUS communication, Fieldbus communication, drooping
control, automatic restart, DC braking, dynamic braking; simple PLC, dwell
