Chapter 1 Introduction of MV200 Series Drive
1.1 Product model
The description of the drive model on the nameplate indicates the information of the product, such as product
series, voltage class of power supply, power class, the software/hardware code of customized product, etc.
MV200 X - 4 T 5.5 - XX - XX
Product Series
G
1
1
P
General
Pump/Fan
5.5kW~400kW
Rated output power
00~ZZ:Software code
for customized product
00~ZZ:Hardware code
for customized product
S: Single-phase
T: Three-phase
2: 220V
4: 380V
1.2 Product nameplate
