222
Register
address
Value to be written
Actual written value
Description
P01.01
0x1194 0x00001194 The 16 high bits is filled with 0x0000.
0xFE0C 0xFFFFFE0C
The 16 high bits is filled with 0xFFFF.
P01.02
0x1194 0x1194
0xFE0C 0xFE0C
(2) Command codes 0x10 and 0x43
These two types of command codes can be used to change multiple function code parameters or control
parameters and they support both 16-bit and 32-bit access modes.
The 16-bit access mode is as described above.
For the 32-bit access mode, the unit of the data to be written is 32 bits.
As shown in the following table, changing 4 continuous function codes with P02.00 as the start address (the
slave address is 5).
Request frame:
Bytes
Value
Description
16-bit mode 32-bit mode
0 0x05 0x05 Slave address
1 0x10/0x43 0x10/0x43 Command code
2~3 0x0200 0x8200
Start address (in the 32-bit mode, the highest byte of the
start address is 1)
4~5 0x0004 0x0008
Number of registers (in the 32-bit mode, the number of
registers is twice of that of parameters)
6 0x08 0x10 Number of bytes of register content
7~8 Value P02.00
Value P02.00
Content to be written:
16-bit operation: 8 bytes in total
32-bit operation: 16 bytes in total
9~10 Value P02.01
11~12 Value P02.02
Value P02.01
13~14 Value P02.03
15~16 Check code
Value P02.02
17~18 -
19~20 -
Value P02.03
21~22 -
23~24 - Check code
If the operation is successful, the response frame is as follows:
