Megmeet MV200 Series User Manual

44
Fig. 3-26 Incorrect grounding method of shielding
3.3.3 Grounding
Dedicated grounding pole (the best)
Fig. 3-27 Grounding diagram 1
Shared grounding pole (acceptable)
Fig. 3-28 Grounding diagram 2
Shared grounding cable (unacceptable)
Fig. 3-29 Grounding diagram 3
PE
PE
Enclosure
Enclosure
Drive Other
equipment
PE
Drive Other
equipment
PE
Drive Other
equipment
PE
