2 Installation requirements
10
On-site requirements of the mains connection
MELAtherm 10 Evolution DTA MELAtherm 10 Evolution DTB
Local requirements Electrical equipment must accord with
DIN VDE 0100.
A main switch (all-pole) should be
fitted on the customer side. This must
be marked as a separator for the
device and be easily accessible for the
operator.
The mains socket must be freely
accessible after set up so that the
device can be disconnected from the
electricity supply at any time.
Electrical power 10.3 kW 3.4 kW
Power supply 3N AC 380-415 V, 50 Hz
Max. voltage range 360-440 V
AC 220-240 V, 50 Hz
Max. voltage range 207-253 V
Electrical connection CEE socket country-specific single-phase
connection with PE protective earth
connection
The connection should be realized with a cable cross-section of 2.5mm
2
.
Building fuses 3x 16 A, separate power circuit with
Type B 16 A fuse, additional RCD
switch with 30 mA
1x 16 A, separate power circuit with
Type B 16 A fuse, additional RCD
switch with 30 mA
Length of the power
cable*
)
2 m
Other Additional socket for the MELAprint 42/44 log printer etc.
*
)
Comply with the specifications in the connection diagram.
PLEASE NOTE
When installing the DTB device version with an ambient temperature above 35°C, it must
be equipped with the EURO-plug CEE3p230V16A instead of the Type F (SCHUKO)
plug in order to connect to the mains.
Water connection
u Do not shorten or damage the feed hose and outlet hose for cold water / DI water.
u Do not remove the dirt filter in the aqua-stop valve of the cold water feed hose.
u Stains on the instruments or the device can develop from poor water quality. To avoid the
development of stains on the instruments or in the washing chamber, MELAG recommends a final
rinse with deionised water (DI water).
Requirements of the water connection
Cold water Demineralized water Wastewater
Length of the
outlet hoses*
)
1.8m
A 3m extension hose can be ordered if required (art.
no.24933).
1.8m
The hose can be replaced
by a 4 m long outlet hose if
required.
Connection in
the practice
To the cold water cut-off
valve (angle valve)
To a water treatment unit
e.g. MELAdem53 /
MELAdem53C
To a separate wall outlet
(DN21) or a flush outflow**
)
(NOTICE!The temperature
of the wastewater can
amount to up to 95°C for
a short while)
Min. flow
pressure
150 kPa (1.5 bar)
Netherlands: 200 kPa (2 bar)
--
Recommended
flow pressure
250 kPa (2.5 bar)
Netherlands: 300 kPa (3 bar)
--
