2 Installation requirements
7
Additional space requirement when using a water treatment unit
Space is required above the MELAdem53 / MELAdem 53 C for clear access to the hose connections.
Dimensions MELAdem 53 MELAdem 53 C
Diameter 24cm 24cm
Height of the unit incl.
connecting parts
57cm 45cm
PLEASE NOTE
If the device is to be installed as a semi-integrated unit, the MELAdem53 /
MELAdem53C can be placed in an adjacent floor unit.
Installation location
Electromagnetic compatibility
When assessing the Electromagnetic Compatibility (EMC) of this device, the emitted interference threshold
values for Class B devices and the stability for operation in an electromagnetic environment as described
in IEC 61326-1 were taken as the basis.
The device is thus suitable for operation in all institutions and domestic settings connected to a public
mains power supply.
The floor should be made of wood or concrete or be tiled with ceramic tiling. If the floor is fitted with syn-
thetic material, the relative humidity must amount to a minimum of 30%.
NOTICE
Steam escaping from the device may cause damage at the adjacent furniture.
n During installation of the device please ensure that the adjacent base cabinets or other
furniture and fittings are resistant to condensation.
Set-up variations
You can set up the device in the following manner:
▪ Free-standing using the optional stainless steel cover plate.
▪ Next to pre-existing under-desk unit in conjunction with the optional stainless steel plate. Space
requirements amount to a minimum of 60cm in width and 60cm depth.
▪ As semi-integrated unit in a pre-existing cavity with a work surface.
▪ Free-standing using the optional stainless steel cover plate and additional floor unit.
PLEASE NOTE
If the device is to be set up with the additional floor unit, then the device must be secured
on the wall using the wall fixture (art. no. 21589), see separate instructions (doc.:
AS_025-17).
