2. Carefully insert the SDM-9220/9230 unit with the attached brackets into the rack.
Secure the front of each bracket onto the rack using two mounting screws with
washers, as shown in
Figure 3-10.
Figure 3-10: Completed Rackmount Installation
Four mounting screws
securely hold unit in place
