Operation Manual Menzi Muck A91 Page 217
Maintenance and Care
8.12 Tightening torque table
Torque Condition Strength class
8.8 10.9 12.9
Torque in Nm
M5 Oiled, lubricated 4.6 6.8 7.9
dry, glued 5.5 8.1 9.5
M6 Oiled, lubricated 8 11.7 13.7
dry, glued 9.5 14 16.4
M8 Oiled, lubricated 19.3 28.3 33.4
dry, glued 23 34 40
M10 Oiled, lubricated 39 57 66
dry, glued 46 68 80
M10x1.25 Oiled, lubricated 41 60 70
dry, glued 49 72 84
M12 Oiled, lubricated 66 97 114
dry, glued 80 117 137
M12x1.5 Oiled, lubricated 69 101 117
dry, glued 84 123 144
M14 Oiled, lubricated 105 154 181
dry, glued 127 186 218
M16 Oiled, lubricated 160 234 274
dry, glued 194 285 333
M18 Oiled, lubricated 220 325 375
dry, glued 265 390 460
M20 Oiled, lubricated 325 460 540
dry, glued 390 560 650
M22 Oiled, lubricated 440 620 730
dry, glued 530 750 880
M24 Oiled, lubricated 555 790 925
dry, glued 675 960 1120
M27 Oiled, lubricated 830 1160 1370
dry, glued 1000 1400 1650
M30 Oiled, lubricated 1120 1575 1865
dry, glued 1350 1900 2250
Note !
Threads and contact surface
Threads and contact surface of the screw head must be oiled or
lubricated.
