Operation Manual Menzi Muck A91 Page 37
Transport, packaging and storage
5.2.2 Loading and unloading
This example illustrates how a standard model Menzi Muck is loaded.
Basic adjustment of the chassis
Warning !
Unintendedoperationduetoinsufcientknowledge
• Can result in death or severe injuries.
• Only load without ramps when you are acquainted and pro-
cient with the machine.
Warning !
Overshoot of permitted overall height during transport
• Can result in death or severe injuries.
• Measure the overall height and correct as required.
Attention !
Incorrect clamping of machine
• Can result in damage to property.
• Only clamp the machine at suitable locations.
15 cm
1. Close the left and right drive
wheel supports fully.
2. Position the steering wheel sup-
ports so that the drive wheels are
parallel to the machine.
3. Lift the excavator chassis approx.
15 cm from the ground.
4. Fully retract the telescopic feet.
