Page 38 www.menzimuck.com
Transport, packaging and storage
Worksteps for loading
1. Place the machine compliant to
the gure on the right straight
behind the truck at a distance of
approx. 1m.
2. Place the boom at a distance of at
least 1m from the edge of the plat-
form onto the loading bridge.
3. Lower the boom until the drive
wheels are at the same height as
the loading bridge.
4. Retract the boom until the machi-
ne moves forward and the drive
wheels reach the loading bridge.
5. Lift the boom so that the drive
wheels stand on the loading
bridge.
6. As soon as the boom is on the
lading bridge, lift the boom and
retract the dipper.
