Control and Display elements
Klepp
1. Longitudinal adjustment of seat including armrest
2. Adjusting weight to driver
3. Height adjustment
4. Longitudinal adjustment of upper seat section
5. Tilt adjustment of backrest
6. Adjustment of backrest
7. Tilt and height adjustment of armrest
7
5
4
3
2
1
6
6.6.2 Operator’s seat
The comfortable operator’s seat makes possible a fatigue-free operation of the machine. Several adjustment
possibilities ensures an optimal adaptation to the operator. For superior ergononomics the control levers are inte-
grated into the seat. The left control lever can be folded back in order to make boarding and disembarking from
cabin easier.
Warning !
Incorrect seating position
• Can result in severe injuries.
• Check and adjust the position of the seat before commencing
work and every time the driver is changed.
