HURTH V-DRIVE TRANSMSSION SERVICE MANUAL NUMBER 23
Page 8D-12 90-861326--1 MARCH 1999
Filling Transmission
IMPORTANT: Use only Automatic Transmission Fluid (ATF) as recommended in
“Lubricants/Sealants.”
1. Fill transmission to proper level, through oil filter cavity. (Refer to “Capacity.”)
2. Install filter as follows:
a. Coat O-ring on filter cover with transmission fluid.
27662
a
b
a-Filter Cover
b-O-Ring
CAUTION
Transmission fluid filter and cover must be properly seated to avoid fluid foaming
and/or loss of fluid, thus resulting in decreased efficiency and/or damage to trans-
mission.
b. Push down until cover is fully seated (top of cover flush with housing), then, Turn
T-handle clockwise until tight.
27666
a
a-Set Screw (Later Models)
3. Start engine and run for two minutes to fill system with fluid.
