Instrumentation and Controls
Page 9A-8 90-863758060 AUGUST 2006
a
b
c
d
e
12118
Typical 14-pin DTS harness
a - Engine harness connector
b - Transmission harness connector
c - Paddle wheel/tank level connector
d - DLC/depth transducer connector
e - Power harness connector/clean
power with 5-amp fuse (DTS only)
