Mercury MERCRUISER - Important Installation Information; Instrumentation; Requirements and Recommendations

Instrumentation and Controls
Page 9A-2 90-863758060 AUGUST 2006
Lubricant, Sealant, Adhesives
Tube Ref No. Description Where Used Part No.
25
Liquid Neoprene
Electrical connections
Electrical connections
92-25711-3
95
2-4-C with Teflon Cable guides and pivot points 92-802859A1
Instrumentation
Requirements and Recommendations
IMPORTANT: This section includes information on Quicksilver's standard (non-digital)
instrumentation and mechanical (cable-actuated) remote controls. Refer to the Smart Craft
applications manual for information on Mercury's new digital instrumentation and remote
controls.
Mercury MerCruiser inboard and tow sports engines, designed to comply with the ABYC
Standards, use the four basic gauges shown below:
• Tachometer
• Oil pressure
• Water temperature
• Voltmeter (battery charge indicator)
An extensive array of Quicksilver gauges, instrumentation harnesses, extension
harnesses, and related accessories are available through Mercury Precision Parts to
satisfy your instrumentation needs. We recommend the use of Quicksilver instrumentation
because they are specifically designed for compatibility with our engines, and engineered
to the same high quality and performance standards. Refer to the Mercury Precision
Parts Accessories Guide for a complete list. Wiring diagrams of some of the basic
instrumentation configurations are provided at the end of this section.
Important Installation Information
Instrumentation should be installed in accordance with the instructions that accompany
them.
!
WARNING
When designing and installing the instrumentation, you must adhere to the applicable
boating industry standards and regulations (NMMA, ABYC, SAE, USCG, EUs, RCD, ISO,
etc.) for the markets where the boat will be sold.
• Ensure that harnesses are routed to avoid getting pinched or chafed.
• Avoid routing the harness in an area where it could be damaged or short circuited later
in the assembly process, such as when a screw is inserted or a hole is drilled.
IMPORTANT: Harness receptacles can be damaged by overtightening clamps.
• The cannon plug connection on the extension harness (at engine and dash) must be
secured with a hose clamp to avoid a loose connection or water entry.
• Support harness every 46 cm (18 in.) using industry approved fasteners. (ABYC
Standard)
• Coat exposed connections on gauges with liquid neoprene to avoid corrosion.
Tube Ref No. Description Where Used Part No.
25
Liquid Neoprene Electrical connections 92-25711-3
