Transmission and Drive Line
Page 2A-8 90-863758060 AUGUST 2006
7370
a
a - Identification plate
ZF MARINE 630 AND 800 SERIES TRANSMISSIONS
On the ZF Marine Down-Angle and V-Drive transmissions, the identification plate indicates
gear ratio, serial number, and model.
14911
8° down angle 12° V-drive
a
7449
a - Identification plate
