Technical Bulletin—TC-9100 Universal Controller 23
The parameters that are dynamically generated by the controller from the
Output Modules and the associated hardware outputs are listed below:
Table 9: Output Module Dynamic Items
Item Tag Item Address
(Hex/Dec)
Description
DO1 1F/31, Bit 6 1 = Digital Output 1 On
0 = Digital Output 1 Off
DO2 1F/31, Bit 7 1 = Digital Output 2 On
0 = Digital Output 2 Off
DO3 1F/31, Bit 1 1 = Digital Output 3 On
0 = Digital Output 3 Off
DO4 1F/31, Bit 2 1 = Digital Output 4 On
0 = Digital Output 4 Off
DO5 1F/31, Bit 3 1 = Digital Output 5 On
0 = Digital Output 5 Off
DO5 1F/31, Bit 4 1 = Digital Output 6 On
0 = Digital Output 6 Off
DO7 1F/31, Bit 5 1 = Digital Output 7 On
0 = Digital Output 7 Off
FOV 26/38, Bit 7 1 = 3-Speed fan override active.
0 = 3-Speed fan in Normal/Automatic mode.
The status of a digital output represents the actual status of the hardware
triac, and is generally only used to monitor on/off, 2-stage, or 3-speed fan
control type outputs. For PAT and DAT outputs, the status of the triacs is
dependent on momentary control requirements and the monitoring of the
triacs is normally only useful for commissioning and troubleshooting
purposes.
Since there are no analog dynamic parameters generated by the output
modules, it is recommended that for analog output types, PAT, and DAT,
the analog source values from the outputs of the programmable modules
be monitored (OCM1 to OCM6).
