Metasys TC-9100 Series User Manual

Technical Bulletin—TC-9100 Universal Controller 67
(See Table 2: Programmable Module Algorithms, in this appendix for
more detailed information.)
Item Type MEM R/W Tag Description
Hex Dec
Programmable Module 1
27 39 Number D W PM1K1 Constant K1
28 40 Connection D WP PM1I1@ Input Connection I1
29 41 Connection D WP PM1I2@ Input Connection I2
2A 42 Connection D WP PM1I3@ Input Connection I3
2B 43 2 Bytes D WP PM1TY
P
Options
2C 44 Number D WP PM1K2 Constant K2
2D 45 Number D WP PM1K3 Constant K3
2E 46 Number D WP PM1K4 Constant K4
2F 47 Number D WP PM1K5 Constant K5
30 48 Number D WP PM1K6 Constant K6
31 49 Number D WP PM1K7 Constant K7
Programmable Module 2
32 50 Number D W PM2K1 Constant K1
33 51 Connection D WP PM2I1@ Input Connection I1
34 52 Connection D WP PM2I2@ Input Connection I2
35 53 Connection D WP PM2I3@ Input Connection I3
36 54 2 Bytes D WP PM2TY
P
Options
37 55 Number D WP PM2K2 Constant K2
38 56 Number D WP PM2K3 Constant K3
39 57 Number D WP PM2K4 Constant K4
3A 58 Number D WP PM2K5 Constant K5
3B 59 Number D WP PM2K6 Constant K6
3C 60 Number D WP PM2K7 Constant K7
Programmable Module 3
3D 61 Number D W PM3K1 Constant K1
3E 62 Connection D WP PM3I1@ Input Connection I1
3F 63 Connection D WP PM3I2@ Input Connection I2
40 64 Connection D WP PM3I3@ Input Connection I3
41 65 2 Bytes D WP PM3TY
P
Options
42 66 Number D WP PM3K2 Constant K2
43 67 Number D WP PM3K3 Constant K3
44 68 Number D WP PM3K4 Constant K4
45 69 Number D WP PM3K5 Constant K5
46 70 Number D WP PM3K6 Constant K6
47 71 Number D WP PM3K7 Constant K7
Programmable
Module
Configuration
Parameters
