Technical Bulletin—TC-9100 Universal Controller 69
Item Type MEM R/W Tag Description
Hex Dec
69 105 2 Bytes F R VER Firmware Version (binary code)
0001 = Version 2
0002 = Version 3
0003 = Version 4
6A 106 not used
6B 107 not used
6C 108 Number D WP HIA1 High Alarm Value AI1
6D 109 Number D WP LOA1 Low Alarm Value AI1
6E 110 Number D WP HIA2 High Alarm Value AI2
6F 111 Number D WP LOA2 Low Alarm Value AI2
70 112 Number D WP HIA3 High Alarm Value AI3
71 113 Number D WP LOA3 Low Alarm Value AI3
72 114 Number D WP HIA4 High Alarm Value AI4
73 115 Number D WP LOA4 Low Alarm Value AI4
74 116 1 Byte D WP OCN1 Output 1 Configuration
X5...X1 Source of Module in binary code
(Numeric Items 0A to 0F, e.g., 0A =
01010)
X8...X6 Output Type
=000 output not used
=001 output for solenoids (PWM) (not used)
=010 0 to 10V Analog Output
=011 On/Off Output
=100 DAT Output
=101 PAT Output (also uses Output 2)
=110 2-Stage On/Off (also uses Output 2)
75 117 Number D WP OCO1 PAT/DAT Timing or Load Rating for
Output Module 1
76 118 1 Byte D WP OCN2 Output 2 Configuration
X5...X1 Source of Module in binary code
(Numeric Items 0A to 0F, e.g., 0A =
01010)
X8...X6 Output Type
=000 output not used (or used with Output 1)
=001 output for solenoids (PWM) (not used)
=010 0 to 10V Analog Output
=011 On/Off Output
77 119 Number D WP OCO2 PAT Dead Band or 2-Stage
Differential for Output 1
Input/Output
Configuration
Parameters
