82 Technical Bulletin—TC-9100 Universal Controller
PM Tag Type Alg. Tag Description
PMxK1 Number K1 not used
PMxI1@ Connection I1@ Input 1 Source
PMxI2@ Connection I2@ Input 2 Source
PMxI3@ Connection I3@ Input 3 Source
PMxTYP 2 Bytes TYP Algorithm Options
X5...X1 Algorithm 7-12 binary code (00111 to 01100)
X8...X6 not used
X12...X9 Conditioning Logic Variable 1
= 0000 No Conditioning
= 0001 Conditioning from Window Open Status
= 0010 Conditioning from Occupancy Status
= 0011 Conditioning from Air Quality Override
= 0100 Conditioning from Reverse Action Status
= 0101 Conditioning from General Alarm Status
= 0110 Conditioning from Low Limit (Anti-freeze)
Status
X16...X13 Conditioning Logic Variable 2
= 0000 No Conditioning
= 0001 Conditioning from Window Open Status
= 0010 Conditioning from Occupancy Status
= 0011 Conditioning from Air Quality Override
= 0100 Conditioning from Reverse Action Status
= 0101 Conditioning from General Alarm Status
= 0110 Conditioning from Low Limit (Anti-freeze)
Status
PMxK2 Number K2 Constant 2
PMxK3 Number K3 Constant 3
PMxK4 Number K4 Constant 4
PMxK5 Number K5 Constant 5
PMxK6 Number K6 Constant 6
PMxK7 Number K7 Constant 7
Algorithm 7:
Average,
Algorithm 8:
Minimum,
Algorithm 9:
Maximum,
Algorithm 10:
Equation 1,
Algorithm 11:
Equation 2,
Algorithm 12:
Equation 3
