Technical Bulletin—TC-9100 Universal Controller 83
PM Tag Type Alg. Tag Description
PMxK1 Number K1 not used
PMxI1@ Connection I1@ Input 1 Source
PMxI2@ Connection I2@ Input 2 Source
PMxI3@ Connection I3@ Input 3 Source
PMxTYP 2 Bytes TYP Algorithm Options
X5...X1 Algorithm 13 (01101)
X13...X6 not used
X14=1 CND1 Input 1 influences the function output only in
COMFORT
X15=1 CND2 Input 2 influences the function output only in
COMFORT
X16=1 CND3 Input 3 influences the function output only in
COMFORT
PMxK2 Number X0 Break Point X0
PMxK3 Number Y0 Break Point Y0
PMxK4 Number X1 Break Point X1
PMxK5 Number Y1 Break Point Y1
PMxK6 not used
PMxK7 not used
Algorithm 13:
Line Segment
Function
