Metasys TC-9100 Series User Manual

Technical Bulletin—TC-9100 Universal Controller 79
PM Tag Type Alg. Tag Description
Loop 1
PMxK1 Number LSP1 Local Set Point
PMxI1@ Connection PV1@ Process Variable Source
PMxI2@ Connection RS1@ Remote Set Point Source
PMxI3@ Connection RV1@ Reference Variable Source
PMxTYP 2 Bytes TYP1 Algorithm Options
X5...X1 Algorithm 3 or 5 (00011 or 00101)
X6=1 Enable Low Limit (Anti-freeze) Override
X7=1 Enable Summer Compensation
X8=1 Enable Winter Compensation
X9=1 Enable Shutoff & OFF Override
X10=1 Enable Manual OFF Fan Override
X11=1 Enable Startup Override
X12=0 Startup Out Level = 0%
X12=1 Startup Out Level = 100%
X13=1 OVR1 Enable Air Quality Override
X14=0 Air Quality Override Out Level = 0%
X14=1 Air Quality Override Out Level = 100%
X15=1 Enable Reverse Action
X16 not used
PMxK2 Number ACT1 Action Type
PMxK3 Number DIF1 Differential
PMxK6 Number BSB1 Set Point Bias During STANDBY
PMxK7 Number BNT1 Set Point Bias During NIGHT
Loop 2
PM(x+1)K1 Number LSP2 Local Set Point
PM(x+1)I1@ Connection PV2@ not used
PM(x+1)I2@ Connection RS2@ Remote Set Point Source
PM(x+1)I3@ Connection RV2@ Reference Variable Source
PM(x+1)TYP 2 Bytes TYP2 Algorithm Options
X5...X1 not used
X6=1 Enable Low Limit (Anti-freeze) Override
X7=1 Enable Summer Compensation
X8=1 Enable Winter Compensation
X9=1 Enable Shutoff & OFF Override
X10=1 Enable Manual OFF Fan Override
X11=1 Enable Startup Override
X12=0 Startup Out Level = 0%
X12=1 Startup Out Level = 100%
X13=1 OVR2 Enable Air Quality Override
X14=0 Air Quality Override Out Level = 0%
X14=1 Air Quality Override Out Level = 100%
X15=1 Enable Reverse Action
X16 not used
PM(x+1)K2 Number ACT2 Action Type
PM(x+1)K3 Number DIF2 Differential
PM(x+1)K6 Number BSB2 Set Point Bias During STANDBY
PM(x+1)K7 Number BNT2 Set Point Bias During NIGHT
Heating/Cooling
On/Off Controller
–Algorithm 3:
Single Output
Algorithm 5:
Dual Output
