Technical Bulletin—TC-9100 Universal Controller 63
Item Type MEM R/W Tag Description
Hex Dec
00 0 1 Byte F R UNIT Device Model: 06h
01 1 Number V R AI1 Analog Input 1 Value
02 2 Number V R AI2 Analog Input 2 Value
03 3 Number V R AI3 Analog Input 3 Value
04 4 Number V R AI4 Analog Input 4 Value
05 5 not used
06 6 not used
07 7 not used
08 8 not used
09 9 2 Bytes V R ADC Selected Analog Input ADC Counter
(see Item 85h, TCS2)
0A 10 Number VR W OCM1 Output Programmable Module 1
0B 11 Number VR W OCM2 Output Programmable Module 2
0C 12 Number VR W OCM3 Output Programmable Module 3
0D 13 Number VR W OCM4 Output Programmable Module 4
0E 14 Number VR W OCM5 Output Programmable Module 5
0F 15 Number VR W OCM6 Output Programmable Module 6
10 16 Number VR W WSP1 Working Set Point Control Module 1
11 17 Number VR W WSP2 Working Set Point Control Module 2
12 18 Number VR W WSP3 Working Set Point Control Module 3
13 19 Number VR W WSP4 Working Set Point Control Module 4
14 20 Number VR W WSP5 Working Set Point Control Module 5
15 21 Number VR W WSP6 Working Set Point Control Module 6
16 22 Number VR W XAI1 External Analog Input 1
17 23 Number VR W XAI2 External Analog Input 2
18 24 Number VR W XAI3 External Analog Input 3
19 25 Number VR W XAI4 External Analog Input 4
1A 26 Number VR W XAI5 External Analog Input 5
1B 27 Number VR W XAI6 External Analog Input 6
1C 28 Number VR R WAC Winter Authority Compensation
1D 29 Number VR R SAC Summer Authority Compensation
Table 1:
Item List
General Dynamic
Parameters
