Metasys TC-9100 Series - Algorithm 1: On;Off Controller; Table 2: Programmable Module Algorithms

Technical Bulletin—TC-9100 Universal Controller 77
PM Tag Type Alg. Tag Description
PMxK1 Number LSP Local Set Point
PMxI1@ Connection PV@ Process Variable Source
PMxI2@ Connection RS@ Remote Set Point Source
PMxI3@ Connection RV@ Reference Variable Source
PMxTYP 2 Bytes TYP Algorithm Options
X5...X1 Algorithm 1 (00001)
X6=1 Enable Low Limit (Anti-freeze) Override
X7=1 Enable Summer Compensation
X8=1 Enable Winter Compensation
X9=1 Enable Shutoff & OFF Override
X10=1 Enable Manual OFF Fan Override
X11=1 Enable Startup Override
X12=0 Startup Out Level = 0%
X12=1 Startup Out Level = 100%
X13=1 OVR Enable Air Quality Override
X14=0 Air Quality Override Out Level = 0%
X14=1 Air Quality Override Out Level = 100%
X15=1 Enable Reverse Action
X16 not used
PMxK2 Number ACT Action Type
PMxK3 Number DIF Differential
PMxK6 Number BSB Set Point Bias During STANDBY
PMxK7 Number BNT Set Point Bias During NIGHT
Table 2:
Programmable
Module
Algorithms
Algorithm 1:
On/Off Controller
