Metasys TC-9100 Series - Worksheet 2: Configuration Parameters - Programmable Modules

Technical Bulletin—TC-9100 Universal Controller 87
Project Name: Completed by:
Controller:
Date:
PM 1 – Algorithm No.:
Item
(hex/dec)
Tag Value
27/39 PM1K1
28/40 PM1I1@
29/41 PM1I2@
2A/42 PM1I3@
2B/43 PM1TYP
2C/44 PM1K2
2D/45 PM1K3
2E/46 PM1K4
2F/47 PM1K5
30/48 PM1K6
31/49 PM1K7
PM 2 – Algorithm No.:
32/50 PM2K1
33/51 PM2I1@
34/52 PM2I2@
35/53 PM2I3@
36/54 PM2TYP
37/55 PM2K2
38/56 PM2K3
39/57 PM2K4
3A/58 PM2K5
3B/59 PM2K6
3C/60 PM2K7
PM 3 – Algorithm No.:
3D/61 PM3K1
3E/62 PM3I1@
3F/63 PM3I2@
40/64 PM3I3@
41/65 PM3TYP
42/66 PM3K2
43/67 PM3K3
44/68 PM3K4
45/69 PM3K5
46/70 PM3K6
47/71 PM3K7
PM 4 – Algorithm No.:
Item
(hex/dec)
Tag Value
48/72 PM4K1
49/73 PM4I1@
4A/74 PM4I2@
4B/75 PM4I3@
4C/76 PM4TYP
4D/77 PM4K2
4E/78 PM4K3
4F/79 PM4K4
50/80 PM4K5
51/81 PM4K6
52/82 PM4K7
PM 5 – Algorithm No.:
53/83 PM5K1
54/84 PM5I1@
55/85 PM5I2@
56/86 PM5I3@
57/87 PM5TYP
58/88 PM5K2
59/89 PM5K3
5A/90 PM5K4
5B/91 PM5K5
5C/92 PM5K6
5D/93 PM5K7
PM 6 – Algorithm No.:
5E/94 PM6K1
5F/95 PM6I1@
60/96 PM6I2@
61/97 PM6I3@
62/98 PM6TYP
63/99 PM6K2
64/100 PM6K3
65/101 PM6K4
66/102 PM6K5
67/103 PM6K6
68/104 PM6K7
Worksheet 2:
Configuration
Parameters –
Programmable
Modules
