38 Technical Bulletin—TC-9100 Universal Controller
The parameters to be defined for each programmable module using the
Line Segment or Signal Span function (Algorithm 13) are listed below.
Refer to
Appendix 2 – Worksheet 2, or Appendix 1 – Table 1: Item List,
for the Item addresses. In the table below,
x in the PM Tag name is the
programmable module number from 1 to 6.
Table 15: Line Segment Algorithm Configuration Items
PM Tag Alg
Tag
Type Description
PMxK1 — Number Not used.
PMxI1@ I1@ Connection
Input 1 (I1)
PMxI2@ I2@ Connection
Input 2 (I2):
(optional)*
PMxI3@ I3@ Connection
Input 3 (I3):
(optional)*
* When not connected, an input assumes a
default value of 0.
PMxTYP TYP 2 Bytes
Algorithm Options
define the behaviour of the
programmable module.
Bits 5…1
Algorithm Number
in binary code:
01101 (0D hex) = Algorithm 13.
Bits 13…6 Not used.
CND1 Bit 14 1 = I1 included only in COMFORT.
CND2 Bit 15 1 = I2 included only in COMFORT.
CND3 Bit 16 1 = I3 included only in COMFORT.
PMxK2 X
0
Number Defines input value for first break point.
PMxK3 Y
0
Number Defines output value at first break point.
PMxK4 X
1
Number Defines input value for second break point.
PMxK5 Y
1
Number Defines output value at second break point.
PMxK6 — Number Not used.
PMxK7 — Number Not used.
The parameters that are dynamically generated by programmable
modules configured as a line segment algorithm are listed below:
Table 16: Line Segment Algorithm Dynamic Items
Item Tag Item Address
(Hex/Dec)
Description
OCM1 0A/10 Output of Programmable Module 1
OCM2 0B/11 Output of Programmable Module 2
OCM3 0C/12 Output of Programmable Module 3
OCM4 0D/13 Output of Programmable Module 4
OCM5 0E/14 Output of Programmable Module 5
OCM6 0F/15 Output of Programmable Module 6
Configuration
Parameters for
Line Segment
Algorithm
Dynamic
Parameters for
Line Segment
Algorithm
