Metasys TC-9100 Series - Worksheet 3: Configuration Parameters - Input;Output and General

88 Technical Bulletin—TC-9100 Universal Controller
Project Name: Completed by:
Controller:
Date:
Analog Inputs
Item
(hex/dec)
Tag Value
6C/108 HIA1
6D/109 LOA1
6E/110 HIA2
6F/111 LOA2
70/112 HIA3
71/113 LOA3
72/114 HIA4
73/115 LOA4
Outputs 1 and 2
74/116 OCN1
75/117 OCO1
76/118 OCN2
77/119 OCO2
Outputs 3 and 4
78/120 OCN3
79/121 OCO3
7A/122 OCN4
7B/123 OCO4
Outputs 5 and 6
7C/124 OCN5
7D/125 OCO5
7E/126 OCN6
7F/127 OCO6
Output 7
80/128 OCN7
81/129 OCO7
General Parameters
83/131 ALG
85/133 TCS2
87/135 TCS1
Analog Input 1
Item
(hex/dec)
Tag Value
89/137 HRI1
8A/138 LRI1
8B/139 FTC1
8C/140 OFS1
8D/141 IOP1
Analog Input 2
8E/142 HRI2
8F/143 LRI2
90/144 FTC2
91/145 OFS2
92/146 IOP2
Analog Input 3
93/147 HRI3
94/148 LRI3
95/149 FTC3
96/150 OFS3
97/151 IOP3
Analog Input 4
98/152 HRI4
99/153 LRI4
9A/154 FTC4
9B/155 OFS4
9C/156 IOP4
Summer/Winter Compensation
9F/159 OT@
A0/160 SPW
A1/161 SPS
A2/162 WA
A3/163 SA
AA/170 WAL
AB/171 SAL
Low Limit (Anti-freeze) Module
A4/164 FT@
A5/165 FSP
A6/166 FDIF
Worksheet 3:
Configuration
Parameters –
Input/Output
and General
