Technical Bulletin—TC-9100 Universal Controller 81
PM Tag Type Alg. Tag Description
Loop 2
PM(x+1)K1 Number LSP2 Local Set Point
PM(x+1)I1@ Connection PV2@ not used
PM(x+1)I2@ Connection RS2@ Remote Set Point Source
PM(x+1)I3@ Connection RV2@ Reference Variable Source
PM(x+1)TYP 2 Bytes TYP2 Algorithm Options
X5...X1 not used
X6=1 Enable Low Limit (Anti-freeze) Override
X7=1 Enable Summer Compensation
X8=1 Enable Winter Compensation
X9=1 Enable Shutoff & OFF Override
X10=1 Enable Manual OFF Fan Override
X11=1 Enable Startup Override
X12=0 Startup Out Level = 0% or Low Limit value,
whichever is lower
X12=1 Startup Out Level = 100%
X13=1 OVR2 Enable Air Quality Override
X14=0 Air Quality Override Out Level = 0% or Low
Limit value, whichever is lower
X14=1 Air Quality Override Out Level = 100%
X15=1 Enable Reverse Action
X16=0 0.1% Error Dead Band
X16=1 1% Error Dead Band
PM(x+1)K2 Number PB2 Proportional Band
PM(x+1)K3 Number TI2 Integral (Reset) Timing
PM(x+1)K4 Number HIL2 Upper Limit of the Control Output
PM(x+1)K5 Number LOL2 Lower Limit of the Control Output
PM(x+1)K6 Number BSB2 Set Point Bias During STANDBY
PM(x+1)K7 Number BNT2 Set Point Bias During NIGHT
