70 Technical Bulletin—TC-9100 Universal Controller
Item Type MEM R/W Tag Description
Hex Dec
78 120 1 Byte D WP OCN3 Output 3 Configuration
X5...X1 Source of Module in binary code
(Numeric Items 0A to 0F, e.g., 0A =
01010)
X8...X6 Output Type
=000 output not used
=011 On/Off Output
=100 DAT Output
=101 PAT Output (also uses Output 4)
=110 2-Stage On/Off (also uses Output 4)
79 121 Number D WP OCO3 PAT/DAT Timing or Load Rating for
Output Module 3
7A 122 1 Byte D WP OCN4 Output 4 Configuration
X5...X1 Source of Module in binary code
(Numeric Items 0A to 0F, e.g., 0A =
01010)
X8...X6 Output Type
=000 output not used (or used with Output 3)
=011 On/Off Output
7B 123 Number D WP OCO4 PAT Dead Band or 2-Stage
Differential for Output 3
7C 124 1 Byte D WP OCN5 Output 5 Configuration
X5...X1 Source of Module in binary code
(Numeric Items 0A to 0F, e.g., 0A =
01010)
X8...X6 Output Type
=000 output not used
=011 On/Off Output
=100 DAT Output
=101 PAT Output (also uses Output 6)
=110 2-Stage On/Off (also uses Output 6)
=111 3-Speed Fan Control (also uses
Outputs 6 and 7)
7D 125 Number D WP OCO5 PAT/DAT Timing, Load Rating for
Output Module 5, or Fan Speed Break
Point 1
