Metasys TC-9100 Series User Manual

Technical Bulletin—TC-9100 Universal Controller 71
Item Type MEM R/W Tag Description
Hex Dec
7E 126 1 Byte D WP OCN6 Output 6 Configuration
X5...X1 Source of Module in binary code
(Numeric Items 0A to 0F, e.g. 0A =
01010), or
Source of 3-speed fan override
(Numeric Items 01 to 04, e.g. 03 =
00011)
X8...X6 Output Type
=000 output not used (or used with Output 5)
=011 On/Off Output
7F 127 Number D WP OCO6 PAT Dead Band, 2-Stage Differential
for Output 5, or Fan Speed Break
Point 2
80 128 1 Byte D WP OCN7 Output 7 Configuration
X5...X1 Fan Speed Differential in binary code
(1...31%, e.g., 10%= 01010)
X8...X6 Output Type
=000 output not used (or used with Output 5)
81 129 Number D WP OCO7 Fan Speed Break Point 3

Metasys TC-9100 Series Specifications

General

Brand	Metasys
Model	TC-9100 Series
Category	Controller
Language	English
